Description
- Sarv manufactures a complete range of high precision alignment turn plates designed to deliver accurate wheel alignment measurements in professional workshop environments. For truck and bus alignment operations, turn plates must withstand heavy loads while providing smooth and controlled wheel movement.
- The Wheel Alignment Turn Table for Truck / Buses (Code: 1100317) is engineered for heavy commercial vehicle applications. It provides free-floating 360-degree movement in all directions, supported by 120 Delrin balls housed in a plastic cage. This low-friction ball system ensures smooth tyre rotation during alignment procedures, even under heavy vehicle loads.
- Manufactured from cold rolled (CRC) steel sheet, the unit is finished with a light blue powder coating for corrosion resistance and long-term durability. The turn plate includes a dual pin locking system that keeps the slip plate stable and zeroed while the vehicle drives onto it or when the plates are not in use.
- An easy-to-read ±0° to 60° scale supports accurate measurement of caster, camber, and steering alignment angles. With a high load capacity of 7000 kg per plate, these alignment turn plates are suitable for heavy-duty truck and bus wheel alignment operations in professional service centers and fleet workshops.
Technical Specifications
Capacity: 7000 kg each (7 Ton per plate)
Scale Range: ±0° to 60°
Size: L-480 mm × W-480 mm × H-74 mm
Top Plate Diameter: 480 mm
Weight: 45.000 kg
Material: Cold Roll (CRC) steel sheet
Finish: Light blue powder coated (anti-rust)
Ball System: 120 Delrin balls (plastic balls in cage)
Movement: 360° free-floating
Additional Features: Dual pin lock, built-in handle, auto-centering design
Packing Details
Box Size: 70 × 51 × 17 cm
No. of Pieces per Box: 1 pc
Gross Weight: 46.200 kg
